BM 26 | Palfinger UK

BM 26

All the features needed for straightforward ‘lift and place’ tasks.

KEY FEATURES

Protected hose guidance
Hydraulic supply to auxiliary equipment
Sophisticated geometry
6 function radio remote control
High speed boom extension
Cathodic dip painting
Single-link plus
Paltronic electronics monitoring
HPSC-E

Technical Data
Lifting Capacities

Max. Lifting Moment	13.9 mt/136.4 kNm
Max. Lifting Capacity	6100 kg/59.8 kN
Slewing angle	420°
Slewing torque	1.6 mt/15.7 kNm
Stabiliser spread (std./max.)	5.0 m/6.6 m
Fitting space required	0.83 m
Max. operating pressure	350 bar
Recommended pump capacity	from 50 l/min to 70 l/min
Dead weight (std)	1749 kg

Max 6100 kg / 59.8 kN

4.0 m 13' 1" 3350 kg / 32.9 kN

6.0 m 19' 8" 2200 kg / 21.6 kN

8.0 m 26' 3" 1620 kg / 15.9 kN

BM 26
